Lubricating Oil Pump Lubricating Oil Pump Lubricating Oil Pump

Lubricating Oil Pump

FOB Price:
US 168-5600 / Set
Min.Order Quantity:
1 Set/Sets
Supply Ability:
500 Set/Sets per Month
Port:
Ningbo/Shanghai/Tianjin
Place of Origin:
Zhejiang, China (Mainland)
Payment Terms:
L/C,T/T,Western Union
Brand:
YonJou
Products Model:
KCB
Share:
  • Products Details
  • Company Profile

Quick Details

  • Brand Name: YonJou

    Model Number: KCB

    Place of Origin: Zhejiang, China (Mainland)

Packaging & Delivery

  • Packaging Details: Standard export plywood case lubricating oil pump
  • Delivery Detail: 7 days after paying full amount normally

Specifications

Lubricating Oil Pump

Product Description

Summarize:



1. Lubricating Oil Pump is designed for pumping light fuel oils such as diesel, kerosene, and biodiesel. It is also possible to pump vegetable oil, motor oil, and even glycerol.

2. It is helical gear pump, and built-in by-pass valve. For pumping clean viscous liquids, not containing abrasive or solid particles.

3. They can run dry for only intermediate amounts of time, allowing for the use of a suction hose for collecting fluids from a tank. They should not be run dry for an extended period of time as oil is required to lubricate the pump head.



Generally used in:

  • Petrochemicals: Pure or filled bitumen, pitch, diesel oil, crude oil, lube oil etc.
  • Chemicals: Sodium silicate, acids, plastics, mixed chemicals, isocyanates etc.
  • Paint and ink.
  • Resins and adhesives.
  • Pulp and paper: acid, soap, lye, black liquor, kaolin, lime, latex, sludge etc.
  • Food: Chocolate, cacao butter, fillers, sugar, vegetable fats and oils, molasses, animal food etc.

Product details:



Working Principle: Double Gears
Pump body material: Cast Iron, SS304, SS316
Gear material: #45 Steel, Copper, SS304, SS316
Temperature range:  Normal ≤ 70 C, Special  ≤ 300 C
Driver: Motor engine, diesel engine
Power specs: 220V, 240V, 380V, 400V, 415V, 440V, 460V,  50hz/60hz
Max flow rate: 9600 L/min
Max discharge pressure: 1.45MPa
Type of connection: Quick couple, Thread, Flange
Shaft seal type:   Oil seal, mechanical seal, graphite seal
Sliding bearing: Good aseismic performance
Helical Gear:

Good meshing performance, steady transmisson of gear reduce noise.



Performance Data:





Model

Flow rate

(L/min)

Max Pressure

(Mpa)

Max Power
(kW)

Inlet&Outlet

(mm)

KCB18.3

18.3

1.45

 1.5

20

KCB33.3

33.3

1.45

 2.2

20

KCB55

55

 3

25

KCB83.3

83.3

1

 4

40

KCB133

133

1

 5.5

50

KCB200

200

1

7.5

50

KCB300

300

1

11

80

KCB483.3

483.3

1

11

80

KCB633

633

0.8

 22

100

KCB960

960

0.6

 30

100

KCB1200

1200

0.6

 37

150
